Discharge Performance Test Chamber

Product Description

High Rate Discharge test is a vital quality test toensure the reliability of batteries. An electrical load test after formationcharging is essential to assure performance and quality by discharging thebattery at a high current for a short time period. The machine is equipped withreject station as standard.

Features

• Efficient Production and High Productivity
• Up to 8 batteries/minute
• 9% Correct test
• Automatic Testing System
• High Standards for Health, Safety and Environment

High ratedischarge test is a vital quality test to ensure the reliability of batteries.An electrical load test after formation charging is essential to assureperformance and quality by discharging the battery at a high current for ashort time period. The machine is equipped with reject station as standard.

• For automotive batteries from 36Ah to 240Ah
• Automatic high rate discharge test for automotive batteries
• Easy battery centering and positioning system with pre-adjusted fixtures
• Reject station for failed batteries
• Water Cooling system for testing cables
• Protection against overcurrent, overheat
• Enclosure IP 20

Optional Features

• OCV, CCV, Delta V test devices

Capacity

• Up to 8 Batteries / minute

Operational Range

• Main System Voltage 380V, 3P+PE 50Hz
• Discharge Current: 1500 A, max. 3000 A

Technical Data

• Siemens PLC system
• Festo Pneumatic System
• Siemens or Sew Euro Drive Servo Motors
• Installation Power: 2 kW
• Electrical Power Consumption: 2 kW
• Air Pressure: 5-7 bar
• Air Consumption: 40,5 liters/min
